Multiple Channels Metal Box Power Supply 36W

Multiple Channels Metal Box Power Supply

Wide range AC 100-240V 50/60Hz Input / 12Vdc 3A 36W Output 4 channels outputs metal box centralized power supply

Adjustable output voltage
With four channels outputs
With 3pins AC plug design
Durable white baking finish shell
Wall-hanging design, easy installation
Professional outdoor rainproof design
Output current with PTC self recovery fuse
High power factor correction>0.95
With Protection of over current, over voltage, over load, over temperature, short circuit.

Model No.		XED-3A12VX-4L
OUTPUT	DC voltage	12V
	Rated current	3A
	Current range	4-6A
	Rated power	36W
	No. of Channels	4 channels
	Battery backup	Non-battery backup
	Fuse type	PTC fuse
	Ripple & Noise	120mv
	Voltage adjustment range	11.4-12.6V
	Voltage Accuracy	±5%
	Linear adjustment rate	±1%
	Load adjustment rate	±5%
INPUT	Voltage range	100-240V
	AC Plug	3 PINS
	Frequency range	50/60Hz
	Efficiency	86%
	Surge current	4kV
	Leakage current	0.25mA
PROTECTION	Over load	105%-150%
PROTECTION	Over voltage	18V
ENVIRONMENT	Working temperature	0-40℃
ENVIRONMENT	Storage temperature and humidity	-40℃~+70℃
Safety regulation and electromagnetic compatibility	Safety regulations	EN60950-1
	Insulation impedance	>100MΩ
	Withstand voltage	1.5kv
	Electromagnetic interference	EN55032
Others	MTBF	50000Hours
Others	Dimensions	21416571.5MM
