Wide range AC 100V-240V 50/60Hz Input / 12Vdc 30A 360W Output Open Frame Switch Mode Power Supply
| Model No. | XED-D360W12VWT | |
| OUTPUT | DC voltage | 12V |
| Rated current | 30A | |
| Current range | 0-30A | |
| Rated power | 360W | |
| Ripple & Noise | 150mV max | |
| Voltage adjustment range | 12-12.8V | |
| Voltage Accuracy | ±10% | |
| Linear adjustment rate | ±1% | |
| Load adjustment rate | ±5% | |
| INPUT | Voltage range | 180-264V |
| Frequency range | 47-63Hz | |
| Efficiency | ≥87% | |
| Surge current | ＜200A | |
| Leakage current | ＜3.5mA | |
| PROTECTION | Over load | 32-45A |
| Over voltage | 15-20V | |
| ENVIRONMENT | Working temperature | -20 – 55℃ |
| Storage temperature and humidity | -30 – 60℃ | |
| Safety regulation and electromagnetic compatibility | Safety regulations | – |
| Insulation impedance | ≥10MΩ | |
| Withstand voltage | ≥1500V AC | |
| Electromagnetic interference | – | |
| Others | MTBF | 5000h |
| Dimensions | 214.5×113.6×49mm | |
